High-performance titanium pipes for a variety of industrial applications are the speciality of Vipul Pipes and Tubes, a reputable manufacturer and supplier with headquarters in Chennai, India. These pipes, which are used in harsh settings like chemical processing, marine systems, aerospace, and medical industries, are well-known for their remarkable strength, resistance to corrosion, and lightweight characteristics. Vipul ensures exceptional quality, dimensional accuracy, and durability by manufacturing titanium pipes in accordance with international standards such as ASTM B861 and B862. Vipul Pipes and Tubes provides reliable titanium piping solutions to both domestic and foreign markets with cutting-edge infrastructure and a customer-focused philosophy.
Commercially pure titanium (Grades 1–4) or titanium alloys like Grade 5 (Ti-6Al-4V) are used to make titanium pipes. With trace amounts of oxygen, iron, aluminium, and vanadium, they usually contain more than 98% titanium. With tensile strengths ranging from 344 MPa (Grade 2) to 895 MPa (Grade 5), titanium provides an exceptional strength-to-weight ratio. It also exhibits exceptional corrosion resistance in environments that are acidic and rich in chlorides. These pipes are perfect for demanding and specialised applications because they have outstanding ductility, fatigue resistance, and biocompatibility, and they retain structural integrity at high temperatures.
| Titanium Pipe International Specification | ASTM B337 ASME SB337 / ASTM B861 ASME SB861 NACE MRO 175-94, VdTÜV 230/2 |
| Dimensional tolerances | DIN 17861 D3/T3 or closer |
| Standard Specification | ASME, ASTM, AISI, AMS, JIS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB |
| Titanium Seamless Pipe Size |
|
| Grade 2 Titanium Welded Pipe Size |
|
| Titanium Grade 5 EFW Pipe Size |
|
| Titanium Grade 2 Pipe WT | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Grade 5 Titanium Pipe manufacturing techniques | Seamless / ERW / EFW/ Welded / Fabricated / CDW/ LSAW/ Seam-Welded / Redrawn |
| Origin of ASTM B861 Titanium Alloy pipe material | Indian, European, Korean, Japanese |
| Titanium Metal Gr 5 Pipe End Types |
|
| Form | Round, Square, Rectangular |
| Ti Metal Gr 2 Pipe Length | Single Random, Double Random & Required Length End: Plain End, Beveled End, Treaded |
| Titanium Cp Grade 5 Pipe Delivery Condition | Annealed and Pickled, Hot Finished, Polished, Bright Annealed, Cold Drawn |
| Ti-6AL-4V ELI Titanium Pipe Packing |
|
| CP Titanium Pipe Value Added Services | Cut to size, thread, and groove |
| Port | Mumbai, India |
| Stocking distributor of leading Titanium Pipe manufacturers |
|
| CP Titanium Pipe Dimensional Specification | ANSI/ ASME B36.10, B36.19, B2.1 |
| Marking on Ti-6al-4v Titanium Pipe |
|
| Titanium Gr 2 | C | Ti | N | Fe | H | O | V | Al |
| 0.1 max | 99.2 min | 0.03 max | 0.3 max | 0.015 max | 0.25 max | – | – |
| Titanium Gr 5 | C | Ti | N | Fe | H | O | V | Al |
| 0.10 max | 90 min | 0.05 max | 0.40 max | 0.015 max | 0.20 max | 3.5-4.5 | 5.5-6.75 max |
| Titanium Alloy | UNS | Proof strength Rp0.2 MPa min | Tensile Stress Rm MPa min | Elongation A % min |
|---|---|---|---|---|
| Cp Ti Grade 1 | R50250 | 138-310 | 240 | 24 |
| Cp Ti Grade 2 | R50400 | 275-450 | 345 | 20 |
| Cp Ti Grade 3 | R50550 | 380-550 | 450 | 18 |
| Ti Grade 7 | R52400 | 275-450 | 345 | 20 |
| Ti Grade 9 | R56320 | 483 | 620 | 15 |
| Ti Grade 11 | R52250 | 138-310 | 240 | 24 |
| Ti Grade 12 | R53400 | 345 | 483 | 18 |
| Ti Grade 16 | R52402 | 275-450 | 345 | 20 |
| Ti Grade 17 | R52252 | 138-310 | 240 | 24 |
| Ti Grade 26 | R52404 | 275-450 | 345 | 20 |
| Ti Grade 28 | R52254 | 483 | 620 | 15 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Titanium Pipes from Brydon Pipes and Tubes ensures exceptional quality, durability, and performance for demanding industrial applications. Our alloy steel pipes are manufactured using high-grade materials that offer superior resistance to corrosion, high pressure, and extreme temperatures. We adhere to stringent quality control standards to guarantee reliable performance in critical sectors such as oil and gas, power generation, and construction. With a commitment to customer satisfaction, Vipul Pipes and Tubes provides tailored solutions, timely delivery, and expert support, making us a trusted partner for all your alloy steel pipe needs.
Vipul Pipes and Tubes, one of the largest suppliers of Titanium Pipes in Chennai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Titanium Pipes to meet your specific requirements. Our team at Vipul Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@vipulpipesandtubes.co.in.
Because of their exceptional resistance to acids and chlorides, titanium pipes are widely used in the chemical processing industries to transport corrosive fluids and gases. Because of their unparalleled resistance to corrosion, they are perfect for offshore structures, desalination plants, and seawater systems in the maritime industry. Titanium pipes are used in the aerospace and defence sectors for hydraulic systems and structural elements that need to be strong and lightweight. Because titanium is biocompatible, the medical industry uses it in implants and surgical instruments. In order to ensure dependable performance under extreme pressure and temperature conditions, they are also utilised in nuclear reactors, power generation, and automotive systems.
