With its main office in Chennai, India, Vipul Pipes and Tubes is a top producer and supplier of high-performance titanium boiler tubing for demanding industrial uses. Vipul has been providing tubing solutions with exceptional corrosion resistance, high thermal conductivity, and outstanding durability under high-pressure, high-temperature conditions for decades. Their titanium boiler tubes are perfect for power plants, chemical processing facilities, and marine systems because they are designed to meet international standards. Vipul Pipes is now a reputable supplier for vital titanium boiler tubing requirements in a variety of industries thanks to its dependable service, timely delivery, and stringent quality control.
Depending on the needs of the application, titanium boiler tubing is usually composed of commercially pure titanium (Grades 1-2) or alloyed grades such as Titanium Grade 5 or Grade 12. The base element in the composition is titanium, with trace amounts of aluminium, vanadium, or molybdenum added for strength and resistance to corrosion. High tensile strength (up to 550 MPa), low density, exceptional ductility, and superior resistance to scaling and stress corrosion cracking are just a few of these tubes’ exceptional mechanical qualities. They are very effective in boiler and heat exchanger systems because of their resistance to harsh media and high temperatures.
| Standard | ASTM, AISI, GB, JIS, customers’ requests available |
| Size | Round Tube: OD: 16-119mm or customized |
| Thickness | 0.25mm-3.0mm |
| Length | 6m or according to customers’ request |
| Sample | Free sample is available, but freight should be paid by you |
Tolerance | Outer diameter: ±0.2mm |
| Thickness: ±0.05mm | |
| Length: ±0.5mm | |
| Ends | In plain end or beveled ends or as your requirements |
| Welding Line Type | ERW (Electrical Resistance Weld) |
Finishing | A. Sanded |
| B. Gloss #400,Mirror #600 – #1000 | |
| C. Brushed | |
| D. Wood Grain | |
| E. Embossed, Threaded | |
| Application | Decorations, constructions, food industry, etc. |
| Certification | ISO, SGS |
| Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
| Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
| Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
| Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
| Length | 6m or according to customer’s request |
| Outer diameter | 6.35-219mm |
| Tolerance | Outer diameter :±0.2mm |
| Thickness :±0.02mm | |
| Length :±0.5mm | |
| Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
| Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
| Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Titanium Boiler Tubing from Vipul Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Vipul Pipes and Tubes, a leading supplier of Titanium Boiler Tubing in Chennai, India, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Vipul Pipes and Tubes, we provide custom sizes of Titanium Boiler Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@vipulpipesandtubes.co.in.
In industries where corrosion resistance and heat transfer efficiency are crucial, titanium boiler tubing is widely used. Its uses include desalination facilities, petrochemical processing, power generation, marine systems, and aerospace thermal systems. Titanium tubing in boilers and heat exchangers is resistant to scaling and corrosion even in high-pressure, high-temperature, and saline or acidic conditions. This guarantees enhanced system performance, lower maintenance costs, and a longer operational life. Titanium is perfect for food and pharmaceutical-grade steam systems because it is non-toxic and non-reactive. All things considered, it is the material of choice for high-performance, corrosion-resistant boiler tubing applications under demanding industrial settings.
