Home > Super Duplex Steel > Super Duplex Steel Pipes S32750
Based in Chennai, India, Vipul Pipes and Tubes is a well-known producer and supplier of Super Duplex Steel Pipes S32750, providing high-performance piping solutions for businesses that work in harsh environments. These pipes are renowned for their exceptional strength, resilience to pitting, stress corrosion, and crevice corrosion, as well as their longevity. Vipul ensures exceptional quality, accuracy, and longevity by producing Super Duplex S32750 pipes in accordance with international standards such as ASTM A790. Vipul Pipes and Tubes serves vital industries like the oil and gas, chemical processing, desalination, and marine sectors by providing dependable and effective piping solutions that are adapted to satisfy the needs of the global industry.
About 25% chromium, 7% nickel, 4% molybdenum, and additional nitrogen are added to Super Duplex Steel Pipes S32750 to increase their strength and resistance to corrosion. This steel grade offers high yield strength (~550 MPa) and tensile strength (~800–1000 MPa) due to its balanced dual-phase microstructure of ferrite and austenite. These pipes show outstanding resistance to fatigue, erosion, cracking, and stress corrosion caused by chloride. They are perfect for demanding service environments where corrosion resistance and mechanical strength are crucial due to their exceptional weldability and mechanical stability at high temperatures.
| Specification | ASTM A 789 ASME SA 789 |
| Standard Specification | ASME, ASTM, AISI, AMS, JIS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB |
| Size |
|
| Welded Pipes Size |
|
| EFW Pipes Size |
|
| Wall Thickness | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| manufacturing techniques | Seamless / ERW / EFW/ Welded / Fabricated / CDW/ LSAW/ Seam-Welded / Redrawn |
| Origin | Indian, European, Korean, Japanese |
| Form | Round, Square, Rectangular |
| Delivery Condition | Annealed and Pickled, Hot Finished, Polished, Bright Annealed, Cold Drawn |
| Grade | Super Duplex 2507 |
|---|---|
| Carbon | 0.030 |
| Manganese | 1.20 |
| Phosphorous | 0.035 |
| Sulphur | 0.020 |
| Silicon | 0.80 |
| Chromium | 24.0–26.0 |
| Nickel | 6.0–8.0 |
| Molybdenum | 3.0–5.0 |
| Nitrogen | 0.24–0.32 |
| Iron | Bal. |
| Copper | 0.50 |
| Alloy | UNS Designation | Spec. | psi | MPa | ksi | psi | MPa | ksi | Elongation in 2 in. (min.) % | Grain Size Req. | Max. Hardness | Modulus of Elasticity (x106psi) | Mean Coefficient of Thermal Expansion (IN./IN./°F x 10-6) | Thermal Conductivity (BTU-in/ ft2-h-°F) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2507 | S32750 | A789, A790 | 116,000 | 800 | 116 | 80,000 | 550 | 80 | 15 | – | 32 Rc | 27.5 | 7.2 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Duplex Steel Pipes S32750 from Vipul Pipes and Tubes ensures high quality and durability, as these pipes offer excellent corrosion resistance and strength. Our commitment to exceptional service and reliable delivery guarantees customer satisfaction across various industrial applications. Our expertise in stainless steel products ensures you receive a top-tier solution tailored to your needs.
Vipul Pipes and Tubes, one of the largest suppliers of Duplex Steel Pipes S32750 in Chennai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Duplex Steel Pipes S32750 to meet your specific requirements. Our team at Vipul Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@vipulpipesandtubes.co.in.
| Alloy | UNS Designation | Werkstoff NR. | Specifications | AFNOR | Grade | DIN | EN | SS |
|---|---|---|---|---|---|---|---|---|
| 2507 | S32750 | 1.4410 | A/SA789, A/SA790 | Z3 CN 25.06 Az | F53 | X 2 Cr Ni MoN 25.7.4 | 1.4410 | 2328 |
Due to their exceptional resistance to harsh chemicals and seawater corrosion, Super Duplex Steel Pipes S32750 are extensively utilised in chemical processing facilities, offshore and subsea oil and gas operations, and marine environments. These pipes are perfect for applications requiring high strength and corrosion resistance, such as heat exchangers, pressure vessels, desalination plants, and firefighting systems. Long service life and performance dependability are essential in the pulp and paper, power generation, and pharmaceutical processing industries. They are an excellent option for demanding infrastructure and process systems due to their high strength-to-weight ratio and resistance to stress corrosion.
| Pipe OD mm | Pipe WT mm | Nominal size | Weight, kg/m |
|---|---|---|---|
| 21.34 | 2.11 | 1/2″ 10S | 1.02 |
| 21.34 | 2.77 | 1/2″ 40S | 1.29 |
| 26.67 | 2.11 | 3/4″ 10S | 1.30 |
| 26.67 | 2.87 | 3/4″ 40S | 1.71 |
| 33.40 | 1.65 | 1″ 5S | 1.31 |
| 33.40 | 2.77 | 1″ 10S | 2.13 |
| 33.40 | 3.38 | 1″ 40S | 2.54 |
| 42.16 | 1.65 | 1 1/4″ 5S | 1.67 |
| 42.16 | 2.77 | 1 1/4″ 10S | 2.73 |
| 42.16 | 3.56 | 1 1/4″ 40s | 3.44 |
| 48.26 | 1.65 | 1 1/2″ 5S | 1.92 |
| 48.26 | 2.77 | 1 1/2″ 10S | 3.16 |
| 48.26 | 3.68 | 1 1/2″ 40S | 5.49 |
| 60.33 | 1.65 | 2″ 5S | 2.42 |
| 60.33 | 2.77 | 2″ 10S | 3.99 |
| 60.33 | 3.91 | 2″ 40S | 5.52 |
| 73 | 3.05 | 2 1/2″ 10s | 5.35 |
| 73 | 5.16 | 2 1/2″ 40S | 8.77 |
| 88.90 | 2.11 | 3″ 5S | 4.58 |
| 88.90 | 3.05 | 3″ 10S | 6.56 |
| 88.90 | 5.49 | 3″ 40S | 11.47 |
| 101.60 | 3.05 | 3 1/2″ 10s | 7.53 |
| 114.30 | 2.11 | 4″ 5S | 5.93 |
| 114.30 | 3.05 | 4″ 10S | 8.50 |
| 114.30 | 6.02 | 4″ 40S | 16.32 |
| 141.3 | 3.4 | 5″ 10S | 11.74 |
| 141.3 | 6.55 | 5″ 40S | 22.1 |
| 168.3 | 2.77 | 6″ 5S | 11.48 |
| 168.3 | 3.4 | 6″ 10S | 14.04 |
| 168.3 | 7.11 | 6″ 40S | 28.69 |
| 219.1 | 2.77 | 8″ 5S | 15.0 |
| 219.1 | 3.76 | 8″ 10S | 20.27 |
| 219.1 | 8.18 | 8″ 40S | 43.2 |
| 273 | 3.40 | 10″ 5S | 22.95 |
| 273 | 4.19 | 10″ 10S | 28.2 |
| 273 | 9.27 | 10″ 40S | 61.22 |
| 323.9 | 3.96 | 12″ 5S | 31.72 |
| 323.9 | 4.57 | 12″ 10S | 36.54 |
| 323.9 | 9.53 | 12″ 40S | 75.02 |
| 355.6 | 4.78 | 14″ 10S | 41.99 |
| 355.6 | 9.53 | 14″ STD | 82.583 |
| 406.4 | 9.53 | 16″ STD | 94.706 |
| 406.4 | 4.78 | 16″ 10S | 48.07 |
| 457.2 | 4.78 | 18″ 10S | 54.151 |
| 508.0 | 5.54 | 20″ 10S | 69.702 |
| 610.0 | 6.35 | *24″ 10S | 95.919 |
