Home > Stainless Steel > Stainless Steel ERW Pipes
Located in Chennai, India, Vipul Pipes and Tubes is a reputable producer and supplier of high-end stainless steel ERW (Electric Resistance Welded) pipes. These pipes are perfect for industrial and structural applications because of their high performance standards and precision manufacturing. Vipul Pipes and Tubes provides ERW pipes with exceptional strength, dimensional accuracy, and resistance to corrosion. The business has established a strong reputation in a number of industries, including power generation, water treatment, construction, and oil and gas, thanks to its emphasis on innovation, quality control, and on-time delivery. Vipul Pipes and Tubes is dedicated to quality work and enduring client satisfaction.
Grades 304, 316, and 321 of stainless steel ERW pipes are made of iron, chromium (16–18%), and nickel (8–12%), with optional molybdenum and carbon content below 0.08%. These pipes have outstanding mechanical strength, weldability, and resistance to corrosion. Tensile strength of 500–750 MPa, yield strength of 200–250 MPa, and elongation of 35–40% are typical mechanical characteristics. These pipes are appropriate for demanding engineering and fluid transport applications because the ERW manufacturing process guarantees uniformity, smooth finishes, and tight dimensional tolerances.
| Standard Specification | ASTM A312, A270, A249, A269, A268, A358, A213 |
| ANSI / ASME Specification | ANSI/ASME B36.19M, ANSI/ASME B36.10M |
| Shapes and Types we produce | Hex, Hydraulic, Square, Round, Honed, Rectangle |
| Manufacturing Type | Fabricated, 100% X Ray Welded, ERW (Electric Resistance Welded), CDW, Welded |
| Pipe End Forming | Plain One End, Beveled One End, Bevel large end, Bevel one end, Bevel both ends, Beveled end, Bevel small end, Plain Both Ends, Treaded Both Ends, Treaded On End |
| Various TDC Types | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Material Surface Finish | 2B, No.4, No.1, No.8 Mirror Finish or custom Finish as per customer Requirements |
| ASME B36.10 Pipe Schedules | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Available Value Added Services | Color Coding, Cutting, Threading, Grooving, Export Documentation, MTR’s Available, Polishing, Material testing, Beveling, Destructive, Threading, Export Packaging, Destructive, Machining, Non Customer Tagging/ Marking, Ultrasonic Testing |
| Marking |
|
| Grades |
|
| Grade | Elastic Modulus (GPa) | Electrical Resistivity (nΩ.m) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Density (kg/m3) | Specific Heat 0-100°C (J/kg.K) | Thermal Conductivity (W/m.K) | |||
|---|---|---|---|---|---|---|---|---|---|
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| SS ERW Pipe | 193 | 720 | 17.2 | 17.8 | 18.4 | 8000 | 500 | 16.2 | 21.5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel ERW Pipes from Vipul Pipes and Tubes ensures high-quality, corrosion-resistant pipes with excellent durability and strength. We provide reliable performance in demanding environments, and our electric resistance Welded (ERW) process guarantees superior precision and consistency in manufacturing.
Vipul Pipes and Tubes, one of the largest suppliers of Stainless Steel ERW Pipes in Chennai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| Nominal size in Inch | Wall thickness in Inch | Outside diameter in mm | Wall thickness in mm | Outside diameter in Inch | Weight [Kg/M] | Weight [lb/ft] |
|---|---|---|---|---|---|---|
| 1/2 Inch | 0.065 | 21.3 mm | 1.65 | 0.840 | 0.80 | 0.54 |
| 3/4 Inch | 0.065 | 26.7 mm | 1.65 | 1.050 | 1.03 | 0.69 |
| 1 Inch | 0.065 | 33.4 mm | 1.65 | 1.315 | 1.30 | 0.87 |
| 1 1/4 Inch | 0.065 | 42.2 mm | 1.65 | 1.660 | 1.66 | 1.12 |
| 1 1/2 Inch | 0.065 | 48.3 mm | 1.65 | 1.900 | 1.91 | 1.28 |
| 2 Inch | 0.065 | 60.3 mm | 1.65 | 2.375 | 2.40 | 1.61 |
| 2 1/2 Inch | 0.083 | 73.0 mm | 2.11 | 2.875 | 3.71 | 2.49 |
| 3 Inch | 0.083 | 88.9 mm | 2.11 | 3.500 | 4.54 | 3.05 |
| 3 1/2 Inch | 0.083 | 101.6 mm | 2.11 | 4.000 | 5.21 | 3.50 |
| 4 Inch | 0.083 | 114.3 mm | 2.11 | 4.500 | 5.88 | 3.95 |
| 5 Inch | 0.109 | 141.3 mm | 2.77 | 5.563 | 9.52 | 6.40 |
| 6 Inch | 0.109 | 168.3 mm | 2.77 | 6.625 | 11.38 | 7.65 |
| 8 Inch | 0.109 | 219.1 mm | 2.77 | 8.625 | 14.87 | 9.99 |
| 10 Inch | 0.134 | 273.1 mm | 3.4 | 10.750 | 22.76 | 15.29 |
| 12 Inch | 0.156 | 323.9 mm | 3.96 | 12.750 | 31.44 | 21.13 |
| 14 Inch | 0.156 | 355.6 mm | 3.96 | 14.000 | 34.56 | 23.22 |
| 16 Inch | 0.165 | 406.4 mm | 4.19 | 16.000 | 41.83 | 28.11 |
| 18 Inch | 0.165 | 457.0 mm | 4.19 | 18.000 | 47.09 | 31.64 |
| 20 Inch | 0.188 | 508.0 mm | 4.78 | 20.000 | 59.70 | 40.12 |
| 22 Inch | 0.188 | 559.0 mm | 4.78 | 22.000 | 65.75 | 44.18 |
| 24 Inch | 0.218 | 610.0 mm | 5.54 | 24.000 | 83.11 | 55.85 |
| 30 Inch | 0.250 | 762.0 mm | 6.35 | 30.000 | 119.09 | 80.02 |
Yes, we offer custom sizes for Stainless Steel ERW Pipes to meet your specific requirements. Our team at Vipul Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@vipulpipesandtubes.co.in.
Because of their affordability, longevity, and resistance to corrosion, stainless steel ERW pipes are widely used in many different industries. They are used as structural elements in infrastructure and buildings during construction. They are employed in the petrochemical and oil and gas sectors to move gases and liquids under pressure. Because they are hygienic and resistant to corrosion, these pipes are also essential in food processing facilities, water treatment facilities, and chemical industries. ERW pipes are also used in HVAC systems, heat exchangers, and automobile parts. Stainless steel ERW pipes are a dependable answer to contemporary industrial demands because of their strength, adaptability, and simplicity of fabrication.
