Home > Stainless Steel Tubing > Stainless Steel 348H Tubing
A reputable company in Chennai, India, Vipul Pipes and Tubes is a top producer and supplier of stainless steel 348H tubing, which is renowned for its outstanding performance in corrosive and high-temperature conditions. The 348H grade is a stabilised austenitic stainless steel that is perfect for applications requiring extended exposure to high temperatures and is made to meet international quality standards. Vipul guarantees excellent quality, accurate production, and prompt delivery. Their 348H tubing solutions, which provide a long service life and reliable performance, are widely used in heat exchangers, petrochemical processing, and nuclear applications where strength, corrosion resistance, and thermal stability are crucial.
Stainless Steel 348H Tubing has a higher carbon content (up to 0.10%) than SS 348 and is made up of 17–20% chromium, 8–11% nickel, and additional columbium (niobium) and tantalum for stabilisation. At elevated temperatures, this stabilised alloy improves resistance to creep and intergranular corrosion. With a tensile strength between 515 and 750 MPa, a yield strength of at least 205 MPa, and a 30% elongation, the tubing demonstrates exceptional mechanical strength. 348H is appropriate for high-temperature, pressure-bearing applications because it retains its structural integrity and resistance to oxidation when used continuously above 800°C.
| Sizes: | 1/8″ to 24″ |
| ASTM A312 Steel grades: | TP304/304L/304H |
| ASTM A312 Schedules: | STD, XS, XXS, SCH5S, SCH10/10S, SCH20, SCH30, SCH40/40S, SCH60, SCH80/80S, SCH100, SCH120, SCH140, SCH160 |
| Standards: | ASTM A312, ASME SA312 |
| Lengths: | SRL and DRL 5meters up to 11meters available from Stock or Production. |
| Ends: | Plain/Bevelled |
| Element | Content (%) |
|---|---|
| Iron, Fe | 66 |
| Chromium, Cr | 19 |
| Nickel, Ni | 11 |
| Manganese, Mn | 2.0 |
| Silicon, Si | 1.0 |
| Nb + Ta | 0.8 |
| Cobalt, Co | 0.2 |
| Tantalum, Ta | 0.1 |
| Carbon, C | 0.080 |
| Phosphorous, P | 0.045 |
| Sulfur, S | 0.030 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 655 MPa | 95000 psi |
| Yield strength (@ strain 0.200%) | 275 MPa | 39900 psi |
| Izod impact | 120 – 160 J | 88.5 – 118 ft-lb |
| Charpy impact | 160 J | 118 ft-lb |
| Shear modulus (typical for steel) | 77.0 GPa | 11200 ksi |
| Elastic modulus | 190-210 GPa | 27557-30458 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break (in 50 mm) | 45% | 45% |
| Hardness, Brinell (converted from Rockwell B hardness) | 147 | 147 |
| Hardness, Knoop (converted from Rockwell B hardness) | 164 | 164 |
| Hardness, Rockwell B | 85 | 85 |
| Hardness, Vickers (converted from Rockwell B hardness) | 169 | 169 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Stainless Steel 348H Tubing from Vipul Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Vipul Pipes and Tubes, a leading supplier of Stainless Steel 348H Tubing in Chennai, India, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Vipul Pipes and Tubes, we provide custom sizes of Stainless Steel 348H Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@brydonpipesandtubes.co.uk.
Because of its improved creep resistance and thermal stability, stainless steel 348H tubing is frequently utilised in high-temperature and high-pressure applications. It is perfect for boiler tubes, superheaters, heat exchangers, and parts used in the aerospace, power generation, and petrochemical sectors. When long-term use at high temperatures is needed, the tubing performs remarkably well in furnace components and nuclear reactor systems. It is a dependable option for challenging settings that require both structural and corrosion-resistant qualities under thermal cycling conditions because of its resistance to intergranular corrosion and stress rupture, as well as its good weldability and mechanical strength.
