Home > Stainless Steel Tubing > Stainless Steel 202 Tubing
For a variety of industrial, architectural, and structural uses, Vipul Pipes and Tubes, a top manufacturer and supplier in Chennai, India, offers premium stainless steel 202 tubing. Austenitic chromium-nickel-manganese stainless steel SS 202, which offers good mechanical strength, workability, and moderate corrosion resistance, was created as a more affordable substitute for SS 304. Our 202 tubing is expertly crafted with cutting-edge technology to guarantee long-term performance, smooth surface finish, and dimensional accuracy. These tubes are a popular option in the furniture, transportation, construction, and general fabrication industries because they are inexpensive, long-lasting, and perfect for decorative and light-load structural applications.
Chromium (17–19%), Nickel (4–6%), Manganese (7.5–10%), and Carbon (≤0.15%) are the usual elements found in stainless steel 202 tubing. The alloy offers good elongation and hardness, as well as high yield strength (~275 MPa) and tensile strength (approximately 515–750 MPa). It works well in indoor or mildly corrosive environments, despite having less corrosion resistance than SS 304. When cold-worked, SS 202 becomes slightly magnetic, but when annealed, it is non-magnetic. It is perfect for roll forming, bending, and other fabrication processes because of its exceptional formability and good weldability.
Standard | ASTM, AISI, GB, JIS, customers’ requests available |
Size | Round Tube: OD: 16-119mm or customized |
Thickness | 0.25mm-3.0mm |
Length | 6m or according to customers’ request |
Sample | Free sample is available, but freight should be paid by you |
Tolerance
| Outer diameter: ±0.2mm |
Thickness: ±0.05mm | |
Length: ±0.5mm | |
Ends | In plain end or bevelled ends or as your requirements |
Welding Line Type | ERW (Electrical Resistance Weld) |
Finishing
| A. Sanded |
B. Gloss #400,Mirror #600 – #1000 | |
C. Brushed | |
D. Wood Grain | |
E. Embossed, Threaded | |
Application | Decorations, constructions, food industry, etc. |
Certification | ISO, SGS |
Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
Length | 6m or according to customer’s request |
Outer diameter | 6.35-219mm |
Tolerance | Outer diameter :±0.2mm |
Thickness :±0.02mm | |
Length :±0.5mm | |
Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
| Element | Content (%) |
|---|---|
| Iron, Fe | 72 |
| Chromium, Cr | 16.0 – 18.0 |
| Manganese, Mn | 5.50 – 7.50 |
| Nickel, Ni | 3.50 – 5.50 |
| Silicon, Si | 1.0 |
| Nitrogen, N | 0.25 |
| Carbon, C | 0.15 |
| Type | Yield Strength 0.2% offset (KSI) | Tensile Strength (KSI) | % Elongation (2″ Gauge length) | Hardness Rockwell |
|---|---|---|---|---|
| SS 201 Ann | 38 min. | 75 min. | 40% min. | HRB 95 max. |
| SS 201 ¼ Hard | 75 min. | 125 min. | 25.0 min. | 25 – 32 HRC (typical) |
| SS 201 ½ Hard | 110 min. | 150 min. | 18.0 min. | 32 – 37 HRC (typical) |
| SS 201 ¾ Hard | 135 min. | 175 min. | 12.0 min. | 37 – 41 HRC (typical) |
| SS 201 Full Hard | 145 min. | 185 min. | 9.0 min. | 41 – 46 HRC (typical) |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Stainless Steel 202 Tubing from Vipul Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Vipul Pipes and Tubes, a leading supplier of Stainless Steel 202 Tubing in Chennai, India, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Vipul Pipes and Tubes, we provide custom sizes of Stainless Steel 202 Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@brydonpipesandtubes.co.uk.
There are many uses for stainless steel 202 tubing where strength, durability, and affordability are crucial. Architectural railings, furniture frames, kitchenware, transport vehicle tubing, fencing, decorative fixtures, and interior structures are among the frequently used applications. In light structural applications with limited exposure to severe corrosion, it is also frequently used. The tubing is appropriate for both residential and commercial construction projects due to its smooth surface, good strength-to-weight ratio, and ease of fabrication. SS 202 tubing provides outstanding value and performance for general-purpose use, despite not being the best choice for marine or acidic environments.
