Home > Stainless Steel Tubing > Stainless Steel 201 Tubing
Known for its strength, longevity, and affordability, Vipul Pipes and Tubes, a prominent manufacturer and supplier of stainless steel 201 tubing, is situated in Chennai, India. Austenitic chromium-nickel-manganese stainless steel SS 201 has a high tensile strength, outstanding formability, and good corrosion resistance. It is frequently used in light to moderately corrosive environments as a cost-effective substitute for SS 304. Our 201 tubing offers smooth finishes and dimensional accuracy thanks to its meticulous manufacturing and stringent quality standards. Vipul’s SS 201 tubing is perfect for mechanical, decorative, and structural applications and satisfies a variety of commercial and industrial performance standards.
Chromium (16–18%), Nickel (3.5–5.5%), Manganese (5.5–7.5%), and Carbon (≤0.15%) are the usual elements found in stainless steel 201 tubing. With a yield strength of about 275 MPa and a tensile strength of roughly 515–750 MPa, this alloy is stronger than SS 304. Good ductility and work-hardening ability are maintained by SS 201. It works well in mild to moderate conditions but is not as corrosion-resistant as SS 304 in extremely aggressive environments. It is appropriate for applications needing formability and strength at a reduced cost due to its superior mechanical qualities, smooth surface finish, and weldability.
Standard | ASTM, AISI, GB, JIS, customers’ requests available |
Size | Round Tube: OD: 16-119mm or customized |
Thickness | 0.25mm-3.0mm |
Length | 6m or according to customers’ request |
Sample | Free sample is available, but freight should be paid by you |
Tolerance
| Outer diameter: ±0.2mm |
Thickness: ±0.05mm | |
Length: ±0.5mm | |
Ends | In plain end or bevelled ends or as your requirements |
Welding Line Type | ERW (Electrical Resistance Weld) |
Finishing
| A. Sanded |
B. Gloss #400,Mirror #600 – #1000 | |
C. Brushed | |
D. Wood Grain | |
E. Embossed, Threaded | |
Application | Decorations, constructions, food industry, etc. |
Certification | ISO, SGS |
Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
Length | 6m or according to customer’s request |
Outer diameter | 6.35-219mm |
Tolerance | Outer diameter :±0.2mm |
Thickness :±0.02mm | |
Length :±0.5mm | |
Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
| Element | Content (%) |
|---|---|
| Iron, Fe | 72 |
| Chromium, Cr | 16.0 – 18.0 |
| Manganese, Mn | 5.50 – 7.50 |
| Nickel, Ni | 3.50 – 5.50 |
| Silicon, Si | 1.0 |
| Nitrogen, N | 0.25 |
| Carbon, C | 0.15 |
| Type | Yield Strength 0.2% offset (KSI) | Tensile Strength (KSI) | % Elongation (2″ Gauge length) | Hardness Rockwell |
|---|---|---|---|---|
| SS 201 Ann | 38 min. | 75 min. | 40% min. | HRB 95 max. |
| SS 201 ¼ Hard | 75 min. | 125 min. | 25.0 min. | 25 – 32 HRC (typical) |
| SS 201 ½ Hard | 110 min. | 150 min. | 18.0 min. | 32 – 37 HRC (typical) |
| SS 201 ¾ Hard | 135 min. | 175 min. | 12.0 min. | 37 – 41 HRC (typical) |
| SS 201 Full Hard | 145 min. | 185 min. | 9.0 min. | 41 – 46 HRC (typical) |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Stainless Steel 201 Tubing from Vipul Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Vipul Pipes and Tubes, a leading supplier of Stainless Steel 201 Tubing in Chennai, India, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Vipul Pipes and Tubes, we provide custom sizes of Stainless Steel 201 Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@brydonpipesandtubes.co.uk.
201 Stainless Steel Applications where strength, formability, and aesthetics are crucial but extreme corrosion resistance is not necessary frequently use tubing. Architectural structures, furnishings, kitchenware, car trims, handrails, and construction and transportation tubing are among the frequently used applications. Because it offers a balance between performance and economy, SS 201 is also appropriate for industrial equipment in environments that are not very corrosive. Because of its easy fabrication and bright finish, it is widely used in decorative and public infrastructure applications. It is a well-liked option for general-purpose stainless steel tubing due to its mechanical dependability and cost effectiveness.
