Vipul Pipes and Tubes is a leading manufacturer and supplier of high-grade Monel Tubing in Chennai, India. With its corrosion resistance and strength, Monel Tubing is the best choice for demanding industrial applications. Vipul Pipes and Tubes provides tubing solutions as per international standards and to suit standard and customized needs. With a keen emphasis on quality, performance, and customer satisfaction, the company serves a broad spectrum of industries such as marine, chemical processing, and oil & gas. Vipul Pipes and Tubes has gained a reputation for offering consistent performing Monel products.
Monel is mainly made up of Nickel (67%) and Copper (about 28–34%), with minute quantities of Iron, Manganese, Carbon, and Silicon. Monel’s nickel-copper combination is highly resistant to seawater, acids, and alkalis. Monel has very good mechanical qualities, such as tensile strength of about 550–620 MPa and yield strength of about 240–345 MPa, depending upon the grade (e.g., Monel 400 or Monel K500). It has high strength and toughness over a broad temperature range, and good weldability and moderate machinability, thus suitable for severe stress applications.
| End | Plain End, Beveled End, Treaded |
|---|---|
| Monel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Monel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Monel tubing wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Specialize in | Monel Capillary Tube & Other Odd Size Monel Heat Exchanger & Condenser Tubes |
| Monel Tube Standards | ASTM B163, ASTM B730 /ASME SB163, ASME SB730 |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Monel tube Form | Round, Coil, Square, Rectangular, Boiler, Hydraulic, Straight or ‘U’ bent Tubes, Hollow, LSAW Tubes Etc. |
| Monel Tube Type | Seamless, ERW, EFW, Welded, Fabricated |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Marking | All Monel Alloy tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger |
| Monel Alloy Tube Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Monel Alloy tube Length | Single Random, Double Random, Standard & Cut length |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.24max | 28.0-34.0 | 2.50 max | 63.00 min | – |
| Alloy K500 | 0.25 max | 1.50 max | 0.50 max | 0.010max | 27.00 – 33.00max | 0.5 – 2 | 63.00 min | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44g\cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Monel Tubing from Vipul Pipes and Tubes ensures exceptional corrosion resistance, high strength, reliable performance, and superior durability for optimal solutions in various industrial applications.
Vipul Pipes and Tubes, one of the largest suppliers of Monel Tubing in Chennai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for monel products in the region.
Yes, we offer custom sizes for Monel Tubing to meet your specific requirements. Our team at Vipul Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@vipulpipesandtubes.co.in.
Monel Tubing finds extensive applications in industries where strength and corrosion resistance are essential. In the marine application, Monel Tubing is utilized in piping systems, heat exchangers, and fuel tanks because of its superior resistance against saltwater corrosion. In chemical processing, Monel Tubing is well suited for handling acidic as well as alkaline media in storage tanks and reactors. The oil and gas sector employs it in offshore drilling platforms and sour gas conditions. Moreover, it is also used in aerospace for fuel and hydraulic lines, and in nuclear power plants because of its resistance to radiation and thermal conductivity. Monel is also used in musical instruments and medical equipment.
