Vipul Pipes and Tubes from Chennai, India, is a prominent manufacturer and supplier of excellent quality Monel Coil Tubing. The coiled tubes are designed from high-grade Monel alloys that exhibit superior corrosion resistance, seawater, acids, and high-temperature resistance. Vipul Pipes offers precise coil tubing with high mechanical strength, flexibility, and long term service life, perfect for continuous run applications. Widely applied in the chemical, oil & gas, marine, and aerospace industries, Vipul’s Monel Coil Tubing is produced in multiple sizes and grades, addressing both national and international standards for seamless, efficient, and long-lasting performance.
Monel Coil Tubing mostly consists of Nickel (63–70%) and Copper (20–29%), with trace amounts of Iron, Manganese, and Silicon. It possesses high tensile strength (550–620 MPa), yield strength (240–345 MPa), and high ductility. Monel’s superior corrosion resistance in marine and acidic conditions renders it particularly suited for coil configurations under adverse conditions. The continuous form of coil tubing provides long lengths with no joints, minimizing leakage and failure. It also has good thermal conductivity and outstanding performance in cryogenic as well as high-temperature operations.
| End | Plain End, Beveled End, Treaded |
|---|---|
| Monel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Monel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Monel tubing wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Specialize in | Monel Capillary Tube & Other Odd Size Monel Heat Exchanger & Condenser Tubes |
| Monel Tube Standards | ASTM B163, ASTM B730 /ASME SB163, ASME SB730 |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Monel tube Form | Round, Coil, Square, Rectangular, Boiler, Hydraulic, Straight or ‘U’ bent Tubes, Hollow, LSAW Tubes Etc. |
| Monel Tube Type | Seamless, ERW, EFW, Welded, Fabricated |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Marking | All Monel Alloy tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger |
| Monel Alloy Tube Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Monel Alloy tube Length | Single Random, Double Random, Standard & Cut length |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.24max | 28.0-34.0 | 2.50 max | 63.00 min | – |
| Alloy K500 | 0.25 max | 1.50 max | 0.50 max | 0.010max | 27.00 – 33.00max | 0.5 – 2 | 63.00 min | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44g\cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Monel Coil Tubing from Vipul Pipes and Tubes ensures exceptional corrosion resistance, high strength, reliable performance, and superior durability for optimal solutions in various industrial applications.
Vipul Pipes and Tubes, one of the largest suppliers of Monel Coil Tubing in Chennai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for monel products in the region.
Yes, we offer custom sizes for Monel Coil Tubing to meet your specific requirements. Our team at Vipul Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@vipulpipesandtubes.co.in.
Monel Coil Tubing is applied extensively in situations where long, uninterrupted tubing runs are needed in aggressive and corrosive environments. In the oil and gas sector, it is utilized for hydraulic lines, chemical injection lines, and downhole control lines because it has the strength and resistance to sour gases and chlorides. In chemical processing, it’s well suited for transferring aggressive fluids. It is utilized by the marine industries for seawater cooling, fuel lines, and desalination systems. In the field of aerospace and instrumentation, it is used in hydraulic and pneumatic applications. The coiled design provides for easy installation, reduced connections, and effective performance in high-pressure and high-temperature conditions.
